Benefits
Extended scale functions
Accurate
With a maximum tolerance of 0.1% of the forks' load, the RAVAS-320 provides accurate weights, making it perfect for use in warehouses and production environments, such as mixing and batching.
Efficient
By combining the tasks of weighing and moving palletized goods, the RAVAS-320 reduces the labor intensity associated with separate weighing processes. It leads to a more efficient use of labor resources, which helps to save time and reduce costs.
NTEP-certified
The RAVAS-320 comes standard with an NTEP-certified legal-for-trade scale for when you invoice by weight. It can also be equipped with a built-in printer that outputs data such as weights, a numerical ID, date/time, and article or order number.
Real-time Data
Equipped with a digital display, the RAVAS-320 provides real-time weight readings. This feature allows operators to monitor and record weights on the spot, contributing to efficient logistics processes, inventory management, and piece counting.
De RAVAS-320 weighing pallet truck
A top quality weighing hand pallet truck with additional weighing functions available. Suitable for use in both warehouses and production environments. View the extensive benefits, functions, technical specifications and options.
- Weighing capacity
- 5,000 lbs
- Graduation multirange
- 2 lbs graduation at 5,000 lbs capacity
- Maximum tolerance
- 0.1% of the load lifted
- Protection class
- Load cells IP67, indicator IP65
- Dimensions
- Fork length: 45 inches Fork Width: 6.69 inches Fork Height: 3.54 inches Space Underneath Fork: 0.86 inches Maximum Fork Height: 7.08 inches Lifting Height: 3.54 inches Width Over Forks: 21.25 inches
- Functionality
- Automatic and manual zero correction, gross/net weighing, automatic and manual tare, totaling with sequence number, connectivity for RAVAS WeightsApp, automatic switch-off after 30 minutes of non-use, kg/lb toggle
- Option
- Legal for Trade NTEP-certified version, extra exchangeable battery pack, built-in thermal printer, relay setpoint switch for automatic dosing, multirange graduation, stainless steel fork shoes, stainless steel or galvanized truck, pivoting indicator: readout from all angles during dosing, footbrake or handbrake, different fork dimensions, different steering or loading wheels
